V NEXT Two

2/1 channel high power amplifier

2-channel amplifier with state-of-the-art Class D concept, which combines outstanding sound quality with maximum efficiency
Bridgeable output channels for flexible system configurations and maximum power output
High output power of up to 1000 W RMS bridged at 4 Ω – ideal for driving powerful subwoofers
Innovative ACP (Amplifier Control Panel) for intuitive configuration of various amplifier functions, such as:

Precise gain adjustment for optimal signal processing – selectable automatic or manual mode:

Auto Gain Ranging (AGR) automatically detects input sensitivity and sets the gain for maximum sound quality
Manual gain adjustment from 0.5 to 8 Volts in 0.5 V steps for precise adaptation to individual system requirements

V-AMP Link – specially optimized input for connecting a HELIX V Series amplifier for powerful signal amplification in subwoofer or high-power speaker applications
Designed for HELIX DSP products – DirectDSP input perfectly tuned for maximum signal quality and performance
MSM (Mono / Stereo Mode) – allows operation as a powerful mono amplifier for subwoofers or as a stereo amplifier for powerful speaker setups
Stabilized Output Power (SOP) technology for consistent and reliable output performance, regardless of input voltage
Intelligent power management ensures perfect voltage stability across all modern vehicle platforms
Start-Stop capable power supply with extended input voltage range up to 18 V – ideal for modern EV vehicles
Auto Remote switch for amplifier activation without the need for an external remote signal
Compact design with low heat dissipation thanks to extraordinary efficiency

Power RMS ≤ 1% THD+N
- @ 4 Ohms	2 x 200 Watts
- @ 2 Ohms	2 x 400 Watts
- @ 1 Ohm	-
- bridged @ 4 Ohms	1 x 800 Watts
- bridged @ 2 Ohms	-
Max. output power per channel*	Up to 500 Watts RMS @ 2 Ohms Up to 1000 Watts RMS @4 Ohms bridged
Amplifier technology	Class D
Inputs	2 x RCA / Cinch 2 x V-AMP Link 1 x Remote In
Input sensitivity	RCA / Cinch: 0.5 - 8 Volts V-AMP Link: 1.5 - 21 Volts
Input impedance	RCA / Cinch: 3 kOhms V-AMP Link: 13 Ohms
Outputs	2 x Speaker output
Output voltage RCA / Cinch	-
Signal converter for digital input	-
Frequency response	10 Hz - 22,000 Hz
Bass boost	-
Highpass	-
Lowpass	-
Bandpass	-
Subsonic	-
Phase	-
Slope high- / lowpass	-
Slope subsonic	-
Slope subsonic / lowpass	-
Signal-to-noise ratio (A-weighted)	109 dB
Distortion (THD @ 1 kHz, 1 W into 4 Ohms)	< 0.003%
Distortion (THD+N @ 1 kHz, 1 W into 4 Ohms)	< 0.004 %
Distortion (THD @ 100 Hz, 1 W into 4 Ohms)	-
Distortion (THD+N @ 100 Hz, 1 W into 4 Ohms)	-
Damping factor	350
Operating voltage	10.5 - 18 Volts (max. 5 sec. down to 6 Volts)
Idle current	1,400 mA
Fuse	3 x 30 A LP-Mini-fuse (APS)
Power rating	DC 12 V ⎓ 86 A max.
Operating temperature range	-40 °C to +70 °C
Additional features	Auto-Gain-Ranging, Mono / Stereo Mode, Start-Stop capability, V-AMP Link, regulated power supply
Dimensions (H x W x D)	44 x 220 x 180 mm / 1.73 x 8.66 x 7.09”

$1,299.00

Tax included. Shipping calculated at checkout.
